| | | Portable and Self-Contained
Radio Dispatch Console
The Model 4010 (Desktop) and Model 4010R (Rackmount) Radio Consoles are self-contained, single position radio console systems which accommodates up to 12 radio channels and 2 telephone lines. The units are compact and versatile. The Model 4010’s modular design and programmability allow the unit to be configured to meet a wide range of public safety, government, institutional and industrial applications. The Model 4010 is rigidly constructed, and is rated for continuous 7 day/24 hour applications with a proven track record of field reliability under the most demanding conditions. It is also suitable for portable applications, such as temporary or mobile Control Centers. The Model 4010 has programmable function buttons for functions such as group call, channel select, channel mute, and channel patch. There is an integral keypad and LCD to display incoming calls. Two separate speakers are provided to allow the operator to hear selected and monitored audio, with volume levels adjusted on each individual channel. The operator options include a handset, gooseneck or desk microphone, headset and footswitch. Base station control is local or remote, using tone remote control 2970 Hz keytone, DC or E&M. | | | Product FEATURES and CONFIGURATION | - Expandable rackmount or office-styled desktop configuration
- Flexible paging encoder
- Supports DTMF, Motorola/GE Two-Tone, Plectron, 5/6 Tone, Quick Call I (2+2), Knox, and Rotary Dial
| - Accommodates most industry standard radio interfaces including: Tone Remote, DC Remote, Local Control and E&M
- Supports one or two telephone lines with intuitive controls: “answer”, “release”, and “hold”
|
| |
| The IntegratorRD radio dispatch workstation is an operator position designed for use with a Series 4000, which can be configured with up to sixteen IntegratorRD workstations.
A workstation is comprised of IntegratorRD radio dispatch software, a host computer, monitor, and the Model 4217 audio panel.
IntegratorRD offers additional benefits associated with concurrent execution of other, well-behaved NT applications and the potential for a higher degree of functional integration. IntegratorRD is a member of the Integrator Suite, which includes modules specifically designed for Public Safety agencies, including Integrator9-1-1 for call-taking, IntegratorMIS, and other companion Applications for optional communication and information systems. | | | Product FEATURES and CONFIGURATION | -
Supports up to 48 channels — any combination of radio, telephone, intercom or public address -
Up to 16 operating positions — may be mixed with button consoles -
Supports conventional (mouse driven) or touchscreen operation -
Supports networked configuration with centralized configuration file management | - Up to 36 channel resource icons may be presented on one screen
- Six screen select keys allow instant call-up of previously defined screens
- Compatible with conventional (tone, DC, E&M) and trunked wireless applications (EDACS, iDEN, MPT1327/MAP27)
- Integral component of the Integrator Suite
|
|
|
